Motion detector 1-10Vdc with stand-by level
DM TE1 001
DINUY tips to choose your motion detector
137,86€ PVR
Description:
Inflared Movement Detector for 1/10VDC equipments, Led or Fluorescent with stand-by level adjustment:
· Stand-by level: When there is no movement the lights go to the preadjusted level ( 0% ~ 50%) instead of being turned off completely
· Surface mounting.
· Application Examples: Parkings, oficces, schools, hospitals, hotels…
· IR Remote Control for Parameters Adjustment: Time Delay and Brightness.
3 advantajes:
· Save time in the installation.
· Same adjustment for all motion detector of the same Installation.
· Cancel potentiometer control which prevents unwanted manipulations.
- Technical characteristics
- Documents
- Logistics data
Technical characteristics DM TE1 001
| Product reference | DM TE1 001 |
| Power Supply (V) | 230VCA |
| Frequency (Hz) | 50 |
| Consumption | 2W |
| Output channels | 1 |
| Type of load | Ballast or Driver 1/10Vcc |
| Switching capacity (A) | 16 |
| Maximum current input 1/10VDC (mA) | 500 |
| Maximum current output 1/10VDC (mA) | 250 |
| Maximum Number of Equipments | 125 |
| Voltage-free contacts | No |
| Detecting angle (º) | 360 |
| Mounting height (m) | 2.5 |
| Coverage diameter (m) | 7 |
| Maximum number of extra movement sensor | 0 |
| Dimming level (%) | 0 - 50 |
| Minimum Time setting (seconds) | 5 |
| Minimum Brightness level (lux) (min) | 3 |
| Maximum Brightness level (lux) (max) | 100 |
| Tecnology | Infrareds (PIR) |
| Mounting | Surface or ceiling |
| Admits contactor | Yes |
| Zero crossing point | Yes |
| Minimum Working Temperature (ºC) (min) | 0 |
| Maximum Working Temperature (ºC) (max) | 40 |
| Protection Level | IP40, Class II |
Documents DM TE1 001
Product
| Width (mm) | 118.5 |
| Depth (mm) | 45 |
| Height (mm) | |
| Weight (g) | 180 |
| Unit EAN | 8422447014921 |
Packaging
| Type of packaging | BX |
| Packing unit | 1 |
| Packing width (mm) | 118 |
| Packing depth (mm) | 47 |
| Packing height (mm) | 118 |
| Gross packing weight (kg) | 0,18 |
